Jason Jaques explains the various repairs needed on the Commodore PET 4032 in his YouTube video
The computer was reported to be exhibiting a troubling screen wobble, an intermittent keyboard, and a broken cassette unit. However, on initial inspection, the unit was actually entirely non-functional. As the machine had been imported from the USA, the computer was expecting a ~117 V, 60 Hz mains supply. When used previously, with a step-down transformer, the screen had shown a significant wobble. Unfortunately, the unit was now entirely dead. Initial exploration indicated that it may have been plugged directly into the UK 240 V 50 Hz supply. Fortunately, while the fuse had been sacrificed, the machine had survived. Once powered up, again with a step-down transformer, the unit’s own power supply was indeed causing significant interference for the built-in display. To resolve the screen wobble, it was eventually decided to replace the transformer with a modern switching power supply. The keyboard suffered from the common hardening of the carbon pads, which made most of the keys inoperable. This was resolved by resurfacing the contacts to restore conductivity. Equally, the cassette unit was brought back to life by a minor repair to an intermittent power connection. Once operational, the unit was “tested” by (among other things) playing a quick round of Satoshi Matsuoka’s Space Invaders, loaded from cassette as demonstrated in this video.
Additional links: Commodore PET Schematics: https://www.zimmers.net/anonftp/pub/c…
Vintage Computer Federation Forums: https://forum.vcfed.org/
MOS 6502 Pinout (by Bill Bertram / Pixel8): https://en.m.wikipedia.org/wiki/File:…
